Transponder Maker Pro (also known as TMPro keymaker or TMPro2 keymaker) is a programmer and softwares for transponder key making, transponder key programming, transponder key copying and PIN code/ security code calculating. Programmer has to be connected to USB port of computer, it does not require external power supply. Main software user interface.
Supports 14 languages;
Bulgarian, English, French, Portuguese, Polish, Hungarian, Spanish, Serbian, Italian, Czech, Chinese, Greek, Turkish and Romanian.
Programmer and all softwares are auto-updateable to latest version available on server.
TMPro are organized as modular softwares. At begining you can purchase TMPro programmer without any additional softwares and use it only with main software. In the future when job comes to your workshop you can very fast and easy add new softwares by simple software purchasing system.
Free functions of TMPro that comes with main software are:
– Reading and displaying important data of transponders, including but not limiting to serial number, secret key status, configurations, encoding mode etc…
– Reading mileage, VIN and manifacturer part number (where these are stored in key)
– Reading and writing of serial eeproms 93cXX, 24cXX, 25cXXX, 95cXXX, S29190, X5328, some Motorola 912/9S12, Microchip PIC18F252
– Reading Motorola HC805P18 (requires additional adapter)
– Unlocking of locked Megamos Crypto ID48 transponder
– Changing mileage in BMW CAS,FEM and BDC keys
- Payment Options
- Comments (0)
TMPro2 Transponder Key Programmer
Transponder Maker Pro (also known as TMPro keymaker or TMPro2 keymaker) is a programmer and softwares for transponder key making, transponder key programming, transponder key copying and PIN code/ security code calculating. Programmer has to be connected to USB port of computer, it does not require external power supply. Main software user interface.TMPro works with immobilisers eeprom dumps. You must have electronic knowledges and to know how to use soldering-desoldering tools and memory devices programmers.It is your choice what programmer you will use for reading and writing of memory devices – integrated in TMPro memory device programmer or external. In order to program transponder you have to remove immobox/BSI/UCH unit from vehicle, desolder memory device or solder wires on testpoints, and read it. Depending of vehicle memory device can be serial eeprom, Motorola MCU, Microchip PIC MCU, ST10F269 MCU, Texas Instruments MCU etc… Next step is to program transponder. Last step is to solder back memory device, reassemble immobox/BSI/UCH and fit back to car.
TMPro uses various types of transponders and keys.
In TMPro software,in information box below software picture you can find what transponder or key have to be used with particular software module.
Used types are:
– Sokymat Nova, also known as Silca T5 or JMA TP05
– Philips PCF 7935. You can use also Silca T15 or JMA TP14.
– All HITAG2,like Philips PCF 7936,7946,7947 etc… You can use also Silca T14 or JMA TP12.
– Sokymat Magic, also known as Megamos Crypto.You can use also Silca T6 or JMA TP08.
– JMA TPX1 or Errebi TX1
– JMA TPX2 or Errebi TX2
– Chinese CN1 or CN2 or CN5 or YS-01 or K-JMD.
– Texas DST, also known as Texas Crypto or Silca 4D-60 – JMA TP06/TP19
– JMA TPX3/TPX4 or Errebi TX4/TX4A.
Here you can download main software and advertising materials.Files below are readymade for printing vertical banners 200cm/80cm.
